Leviton 100A 120/240V 20 Circuit 20 Spaces Outdoor Load Center Enclosure and Interior with Main Breaker, Model LR210-BDC

Description

The Leviton Outdoor Load Center is easy to install and weather resistant. It features a gray enclosure and a solid cover housing white circuit breakers. Hydraulic-Magnetic Trip Technology allows circuit breakers to operate as intended over a wide range of temperature extremes, -40°C to 70°C, without re-rating. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub.

****For security reasons, we cannot accept returns on load centers.

Benefits

• Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker*
• The entire panel can be wired at rough-in without circuit breakers installed
• At final installation, simply plug-on the circuit breaker No pigtails on circuit breakers
• Copper bus is standard

• Leviton GFCI, AFCI and Dual Function circuit breakers feature our patented reset lockout and will not reset if ground- or arc-fault protection is compromised

• Intuitive LEDs help communicate trip condition and type of fault (AF/GF) and remain illuminated even when the circuit breaker is in the tripped state

Technical Information

Type of Load Center: Main Breaker
Curent Rating: 100 A
Spaces / Circuits: 20 / 20
Voltage: 120/240 V
Busbar Material: Copper, Bright Tin-Plated
Busbar Rating: 224A
Enclosure Material: Galvanized Steel, Gray Baked Enamel
Short Circuit Current Rating: 22 KA
Dimensions: 30.31" H x 15" W x 4.56" D
Ground Connection: 4 AWG - 2/0 AWG Cu/Al
Supply Connections: 3 AWG - 300 MCM Cu/Al
Weight: 42.75 lbs.
NEMA Enclosure Type: NEMA3 Outdoor
Operating Temperature: -40°C to 70°C

Standards and Certifications

CSA Std. C22.2 No. 29-15
Certificate 70170209
UL 67: File E480408
UL50
UL50E
UL869A
