Electrical Boxes, Box Extenders & Covers

Description Arlington’s non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with any single gang device and most steel and non-metallic outlet boxes, providing a level, fully supported wiring device that’s flush with the wall surface. ***Screws are not included, you will need mechanical screws 6-32 long enough for your application *** Benefits Prevents steel boxes from arcing and shorting by creating a barrier between the box and device screws BE1 single gang box extenders are trimmable for use in multiple boxes 2-hour fire rating Complies with NEC 2017, article 314.20 for set back boxes Can be installed without removing device wires Some bulkier devices may not fit. (GFCI Receptacle, USB Charger receptacles, Some Dimmers) Technical Information Model: BE1 Outer Height: 4.188" Screw Distance: 3.281" Outer Width: 2.313" Inner Height: 2.672" Inner Width: 1.667" Inner Depth: 1.813" Colour: White Material: Plastic Trade Size: 1-Gang Documents Brochure Instruction sheet BE1 Line Drawing

Description Arlington non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with any single gang device and most steel and non-metallic outlet boxes, providing a level, fully supported wiring device that’s flush with the wall surface. ***Screws are not included, you will need mechanical screws 6-32 long enough for your application*** Benefits Prevents steel boxes from arcing and shorting by creating a barrier between the box and device screws Complies with NEC 2017, article 314.20 for set back boxes Functions with all standard devices, switches, and GFCIs 2-hour fire rating Manufactured from 105°C continuous use 94V0 rated flame retardant plastic for safer installations Some bulkier devices may not fit. (GFCI Receptacle, USB Charger receptacles, Some Dimmers) Technical Information Model: BE2 Outer Height: 4.188" Screws Height Distance: 3.281" Outer Width: 4.125" Inner Height: 2.672" Inner Width: 3.479" Inner Depth: 1.813" Colour: White Material: Plastic Trade Size: 2-Gang Documents Brochure Instruction sheet BE2 Line Drawing

Description Arlington non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with any single gang device and most steel and non-metallic outlet boxes, providing a level, fully supported wiring device that’s flush with the wall surface. ***Screws are not included, you will need mechanical screws 6-32 long enough for your application *** Benefits Prevents steel boxes from arcing and shorting by creating a barrier between the box and device screws Complies with NEC 2017, article 314.20 for set back boxes Functions with all standard devices, switches, and GFCIs 2-hour fire rating Manufactured from 105°C continuous use 94V0 rated flame retardant plastic for safer installations Larger flange provides extra device support when the wall opening is miscut or oversized Accommodate midi or jumbo cover plates Trimmable along the perforated flange for use with standard plates Some bulkier devices may not fit. (GFCI Receptacle, USB Charger receptacles, Some Dimmers) Technical Information Model: BE3 Outer Height: 4.188" Screws Height Distance: 3.281" Outer Width: 5.937" Inner Height: 2.672" Inner Width: 4.9" Inner Depth: 1.813" Color: White Material: Plastic Trade Size: 3-Gang Documents Brochure Instruction sheet BE3 Line Drawing

Description Arlington non-metallic Low Voltage Mounting Bracket helps you save time and cost when installing low- voltage Class 2 communications, cable tv, and computer wiring. Designed for use with 1/4" or 1" drywall installed on furring strips attached to concrete walls. Benefits Horizontal and vertical mounting options Bracket can be traced for cut out Cheaper than metal brackets Oval hole allows final shifting, straightening of device Brackets can be adjusted to fit various wallboard thickness cUL/ CSA listed Installation on existing construction for class 2 wiring only Technical Information Part #: LV1 Weight: 0.048lbs/each Height: 4.250" Width: 2.500" Colour: Black Material: Plastic Documents Specification Sheet LV1 Line Drawing

Description Arlington’s non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with most 3 1/2'' and 4'' octagonal boxes, providing a level, fully supported wiring device that’s flush with the wall surface. ***Screws are not included, you will need mechanical screws 6-32 long enough for your application *** Benefits Complies with 2017 NEC Article 314.20 Extends box up to 1-1/2” to bring it level with ceiling surface Trims to accommodate shallow boxes or to avoid obstructions Manufactured from 105°C continuous use 94V0 rated flame retardant plastic for safer installations Technical Information Model: BE-1R Height: 4.850'' Width: 4.350'' Colour: White Material: Plastic Documents Brochure Catalogue page Line Drawing

Description Arlington recessed, non-metallic combination power and low voltage TV BOX is the secure, easy way to mount a flat-screen TV flush against a wall. It features power in one side; low voltage in the other for Class 2 wiring of the satellite, cable TV, speakers, surround sound systems and more. Benefits Plugs and connectors stay inside the two-gang box, without extending past the wall Non-metallic box with paintable white trim Easy to install - secure installation in walls up to 1-1 /2" thick Mounting wings hold box securely against the wall in rework projects Boxes screw-mount to stud in new construction Low voltage divider included Can be used with Arlington's SCOOP series entrance plates and hoods cUL listed Technical Information Model: TVBU505GC Height: 6.942" Width: 6.254" Colour: White Material: Plastic Trade Size: 2-Gang Wall Depth: 1/2", 5/8", and up to 1-1/2" Documents Specification Sheet TVBU505 Line Drawing

Description Arlingtons' Recessed TVBU507GC non-metallic combination power and low voltage TV BOX is the secure, easy way to mount a flat-screen TV flush against a wall. It features power in one side; low voltage in the other for Class 2 wiring of the satellite, cable TV, speakers, surround sound systems and more. Benefits Plugs and connectors stay inside the two-gang box, without extending past the wall Non-metallic box with paintable white trim Easy to install - secure installation in walls up to 1-1 /2" thick Mounting wings hold box securely against the wall in rework projects Boxes screw-mount to stud in new construction Low voltage divider included Can be used with Arlington's SCOOP series entrance plates and hoods cUL listed Technical Information Model: TVBU507GC Height: 6.818" Width: 7.930" Colour: White Material: Plastic Documents Specification Sheet TVBU507 Line Drawing

Description Device Boxes are used for outlets, switches, ceiling fixtures, receptacles, and small junction boxes. They keep wires dry and are popular for surface mounted applications. Benefits Cable Pryouts Ends Raised ground screw Plaster ears allow the box to be used in "rework" applications Rugged metallic construction Technical Information Brand: Hubbell Depth: 1-1/2 in. Capacity: 25 cu. in. Cable Clamps: U Gang: 2 Dimensions: 4X3X2.5 in. Part #: 2104LLEU2BAR Documents Hubbell Product Catalog : Page # A5

Description Arlington’s non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with any single gang device and most steel and non-metallic outlet boxes, providing a level, fully supported wiring device that’s flush with the wall surface. Benefits Prevents steel boxes from arcing and shorting by creating a barrier between the box and device screws BE1 single gang box extenders are trimmable for use in multiple boxes 2-hour fire rating Complies with NEC 2017, article 314.20 for set back boxes Can be installed without removing device wires Some bulkier devices may not fit. (GFCI Receptacle, USB Charger receptacles, Some Dimmers) Screws are included in this kit Technical Information Model: BE1BAG Outer Height: 4.188" Screw Distance: 3.281" Outer Width: 2.313" Inner Height: 2.672" Inner Width: 1.667" Inner Depth: 1.813" Colour: White Material: Plastic Trade Size: 1-Gang Documents Brochure Instruction sheet BE1 Line Drawing

Description Junction boxes are used for your home or building's electrical system. Boxes are installed in ceiling or wall junctions. Square boxes are used where multiple conductor runs split into two or more directions, bringing power to a number of electrical devices. They provide protection and a safety barrier for electrical connections. Benefits Raised Ground Screw Rugged metallic construction Self-tapping screws effectively eliminate stripping Technical Information Brand: Hubbell Depth: 2-1/8 in. Capacity: 42 cu. in. Knockouts: K(6), 1/2"(6), 3/4"(2) Dimensions: 4.688X2.125 in. Part #: 72171-KBAR Documents Hubbell Product Catalog : Page # A11

Description The Arlington Recessed TV Box allows your LCD and a flat-screen TV to be placed flush against the wall without the appearance of wires and cables. The B613GC is a non-metallic TV Box for power and low voltage devices, it can be used with new and existing construction. This recessed TV box is great for phone, cable, speaker, and surround sound installations. Benefits The box is recessed so plugs don't extend past the wall Textured, paintable trim plate, covers edges of cut out drywall Positioning tabs for 1/2" wall thickness assure accurate placement of box on stud Great for phone, cable, satellite TV, speaker, and surround sound installations Horizontal or vertical mounting Low voltage separator provided for built-in 2-gang device box so power and low voltage can be combined cUL listed B613GC includes a recessed TV Box with trim plate, low voltage separator, NM cable connector, and installation screws Technical Information Model#: TVB613GC Height: 7.000" Width: 17.000" Colour: White Material: Plastic Documents Specification Shee t TVB613 Line Drawing

Description Flat Blank Square Box Cover, Used on 4 Inches Square Boxes. Use this Hubbell® 4 in. Square Flat Box Cover over a 4 in. Square Box when doing a cross connection. Benefits Rugged metallic construction, manufactured from galvanized steel Rounded corners; designed to match the contours of the utility box Hubbell 52 series covers are designed for use with 52 series boxes Self-tapping screws virtually eliminate stripping CSA, UL, and CEC approved Technical Information Application: Covers are used to close an outlet box. Raised device covers are used for mounting switches or receptacles. Bracket Type: No Bracket Color: Gray Drawn or Welded: Drawn Material: Steel Number of Gang(s): 1-Gang Sub Brand: tradeSELECT Type: Mudring, Cover UPC: 626463000168 Actual Depth: 0.051" Width: 4" Height: 4" Raised Ground: No Weight: 0.23 lb Certified Listed: CSA Documents Brochure

Description Ideal for indoor/outdoor industrial and commercial applications, RAB Design die-cast aluminum boxes with two flex lugs for wall or pole mounting or outdoor outlets, sensors or floods are durable and weatherproof. Perfect for mounting lights, outlets, sensors, and floods. Benefits Stamped galvanized steel tabs for ease of mounting Package includes box, 2 plugs, 2 galvanized steel mounting tabs, 2 screws and a ground screw Durable silver grey powder coat paint finish Technical Information Model: D5613 Knockouts: (3) 1/2 Inch Colour: Grey Certifications: UL Documents Specification sheet

Description The Scoop Cable Entry Device with slotted cover organizes cables in a neat bundle and protects low voltage cables passing through the wall. This device can be used for individual cables or a bundle of Class 2 low-voltage wires, it's easy to install and will complement any decor with its smooth clean white finish. Benefits Can be installed facing in or out The design allows for the pass-through of bigger connectors like HDMI. White, Non-metallic Includes two #6 screws Easy cable insertion Technical Information Part # CED130 Height: 4.111" Width: 1.450" Colour: White Material: Plastic Documents Specification Sheet CED130 Line Drawing

Description The Decorative Cover with 2 holes is perfect for concealing components and can easily be installed. Benefits 5” blank aluminum cover with two holes Package includes cover and screws Ideal for industrial, commercial and residential use 2 x 5mm screw holes Technical Information Finish: White Certifications: UL Documents Specification sheet

Description This Leviton Vertical mount cover is ideal for all outdoor electrical applications. It includes multiple adapter plates to fit your needs. Benefits Convenient - Ruggedly constructed to protect from moisture, debris and insects, while providing easy access to receptacles Durable - UV resistant polycarbonate cover and base protect wiring devices from the elements without breaking, cracking or discoloration Compatible - Designed for use with Leviton GFCI/Decora Outlets Technical information 1-Gang Extra Duty While-In-Use Cover for GFCI/Decora Includes: Adapter plates for Duplex and Single Receptacles Material: Polycarbonate Device mount: vertical Lid: Clear Document Dimensional Data Cleaning instructions

Description Ideal for indoor/outdoor industrial and commercial applications, RAB aluminum boxes are durable and weather resistant. Perfect for mounting weatherproof lights, sensors, and floods. Benefits Cast aluminum box with 5 X 1/2" threaded entries. Each box has two opposing mounting feet, 4 internal posts for mounting covers and 2 additional posts for universal crossbars. All posts 10-24 tapped. Sandblasted aluminum finish is standard Included: (1) Aluminum box (4) Threaded plugs, (1) Neoprene gasket, (1) ground screw, (2) brass cover screws, (1) stamped aluminum cover Technical Information Model: 1/2DVXJ Knockouts/Entries: (5) 1/2" Material: Aluminum Colour: Sandblasted Aluminum Certifications: CSA and UL Documents Specification sheet

Description Arlington Round Low Voltage mounting bracket for low voltage smoke detectors, carbon monoxide detectors, cameras or any low voltage product that mount to a standard 4" fixture box. Benefits Adjusts to fit 1/4" to 1-1/2" wall or ceiling thickness. Bracket is its own template for cut out. Trace hole along the inside diameter of the bracket. Cut along the outside of the line. UL/CSA Listed. Technical Information Weight: 0.082 lbs/each Height: 4.375" Width: 4.375" Color: Black Material(s): Plastic Documents Line Drawing Spec Sheet

Description Cover and protect your receptacles and plugs in style with Low profile IN-AND-OUT covers that will keep your homes design looking elegant while giving you access to a reliable outdoor power source. In-and Out covers make using outdoor plugs worry-free; don't worry about bugs, debris or weather conditions damaging your receptacle, Arlington IN-and-OUT covers are bug-proof when not in use, and are weatherproof to withstand extreme weather conditions. Benefits Fits over standard size boxes and openings in new and existing construction Weatherproof, UV-rated plastic cover Removable, cover for easy installation Paintable cover Easily expand and retract cover Bug proof, no open spaces or holes Complies with NEC 2017 Section 406.9 (B) for the protection of exterior outlets which require the use of an extra-duty weatherproof while-in-use cover for all outdoor 15 or 20 AMP receptacles UL & CSA listed Includes: 1 Low profile cover, 1 Standard Duplex, and 1 standard GFCI faceplate, screws and installed gasket Technical Information Model: 60VC Height: 6.274" Width: 3.752" Material: UV-Rated Plastic Style: Vertical Trade Size: 1-Gang Documents Specification Sheet 60VC Line Drawing

Description The DEX-5 extension ring is made of die-cast aluminum with four 1/2” conduit entries. Benefits The package includes extension ring and 4 plugs Weather-resistant Ideal for industrial and commercial use Technical Information Model: DEX-5 VXJ Knockouts: 4 X1/2 Inch Finish: Aluminum Certifications: UL Documents Specification sheet

Description The Scoop Series includes this reversible non-metallic cable entrance hood, for existing cables. The CED1 is a simple, cost-effective way to manage and organize all your cables. This device offers versatile installation options; it can be installed facing in or out, or upside down for cables to feed-out upward. The CED1 hood gives every cable application a clean, professional, decorative finish. Benefits Easy installation Designed to install low-voltage Class 2 only Reversible for installation versatility—Use it facing in, out or upward Protects low voltage cable against damage Best way to run cable where you need it CED13 provides the widest opening for cables with large connectors Includes 2 #6 screws Technical Information Height: 4.111" Width: 1.295" Color: White Material: Plastic Trade Size: 1-Gang Documents Specification Sheet CED1 Line Drawing

Description The FS-C 1 gang aluminum cover is a stamped aluminum cover for 1 gang rectangular boxes. Perfect for indoor and outdoor industrial or residential applications. Benefits Includes: (1) gasket and (2) mounting screws Natural Aluminum finish Technical Information Model: FS-C Screw holes: 2 Colour: Aluminum Certifications: UL Documents Specification sheet

Description Arlington non-conductive box extenders, extend set back metal or non-metallic electrical boxes up to 1-1/2 inches, the easy way. They work with any single gang device and most steel and non-metallic outlet boxes, providing a level, fully supported wiring device that’s flush with the wall surface. ***Screws are not included, you will need mechanical screws 6-32 long enough for your application *** Benefits Prevents steel boxes from arcing and shorting by creating a barrier between the box and device screws Complies with NEC 2017, article 314.20 for set back boxes Functions with all standard devices, switches, and GFCIs 2-hour fire rating Manufactured from 105°C continuous use 94V0 rated flame retardant plastic for safer installations Larger flange provides extra device support when the wall opening is miscut or oversized Accommodate midi or jumbo cover plates Trimmable along the perforated flange for use with standard plates Some bulkier devices may not fit. (GFCI Receptacle, USB Charger receptacles, Some Dimmers) Technical Information Model: BE4 Outer Height: 4.188" Screws Height Distance: 3.281" Outer Width: 7.749" Color: White Material: Plastic Trade Size: 4-Gang Documents Brochure Instruction sheet BE4 Line Drawing

Description Device Box, 1.5 Inches Deep, Gangable, NMD90 and BX90. This shallow Hubbell® Gangable Device Box of 1-1/2 inches deep, is mostly used with a party wall. Its Universal cable clamps secure both nonmetallic sheathed cable (NMD) and armoured cable (AC). Technical Information Bracket Type: No Bracket Color: Gray Drawn or Welded: Welded Ends Cable: 4 Gangable: Yes Material: Steel Number of Gang(s): 1-Gang Plaster Ears: No Sub Brand: tradeSELECT Type: Switch Box, Box Wiring System: Non-Metallic Sheathed (NMD)/ Armoured Cable (AC) 14/2 8/3 Actual Depth: 1.5 in Raised Ground: Yes Weight: 0.33 lb Cable Entry: Universal Cable Clamps Certified Listed: CSA Industry Standard(s): CSA Certified

Description Arlington non-metallic Screw-on Low Voltage mounting bracket helps you easily secure mounting brackets to studs with screws. Use the LVS1 and save on installation and costs. Benefits Non-metallic Eliminates push back Screw on to wood or metal studs in new construction Low voltage Class 2 only Screws included UL/CSA listed Allows wallplate to be applied flush to the wall surface Built-in loop for tying off cable Ready to install, screws come attached and parked in place Installs in 25% less time than steel and plastic mud rings Technical Information Trade Size: 1-Gang Style: Screw-on Weight: 0.069 lbs/each Height: 4.170" Width: 3.13" Color: Black Material: Plastic Certifications: UL, & CSA listed Documents LVS1 Catalog Page Specification sheet Line Drawing

Description The DC100 aluminum cover is made with one 1/2’’ opening. Benefits Package includes cover, neoprene gasket, and two brass screws Ideal for industrial and commercial use Weather-resistant Technical Information Model: DC100 Knockouts: One 1/2 Inch Finish: Silvery Grey Certifications: UL Documents Specification sheet

Description For new work only. This Rab ceiling fan/fixture box mounts directly to a joist for a super secure installation. It is 2 inches deep and has 20 cu.in. Features No loose parts to misplace, totally self contained! Combination hex/philips head screws for easy installation with power screwdrivers CSA Rated up to 70 lb Includes NM cable connector, multiple KOs, 4 installation screws and 2 screws for fan/fixture bracket installation Technical information Width corner to corner: 4.25 in Width side to side of the box: 3.572 in Depth: 2.5 in Bracket length: 6 in Document Catalogue page

Description Arlington non-metallic Screw-on Low Voltage mounting bracket helps you easily secure mounting brackets to studs with screws. Use the LVS2 and save on installation and costs. Benefits Non-metallic Eliminates push back Screw on to wood or metal studs in new construction Low voltage Class 2 only Screws included UL/CSA listed Allows wallplate to be applied flush to the wall surface Built-in loop for tying off cable Ready to install, screws come attached and parked in place Installs in 25% less time than steel and plastic mud rings Technical Information Trade Size: 2-Gang Styl: Screw-on Weight: 0.069 lbs/each Height: 4.170" Width: 5.492" Color: Black Material: Plastic Certifications: UL, & CSA listed Documents LVS2 Catalog Page Specification sheet Line Drawing

Description Cover and protect your receptacles and plugs in style with Low profile IN-AND-OUT covers that will keep the design of your home looking elegant while giving you access to a reliable outdoor power source. In-and Out covers make using outdoor plugs worry-free; don't worry about bugs, debris or weather conditions damaging your receptacle, Arlington IN-and-OUT covers are bug-proof when not in use, and are weatherproof to withstand extreme weather conditions. Benefits Fits Over-sized boxes and openings in new and existing construction Weatherproof, UV-rated plastic cover Removable, cover for easy installation Paintable cover Easily expand and retract cover Bug proof, no open spaces or holes Complies with NEC 2017 Section 406.9 (B) for the protection of exterior outlets which require the use of an extra-duty weatherproof while-in-use cover for all outdoor 15 or 20 AMP receptacles UL & CSA listed Includes: 1 Low profile cover, 1 Standard Duplex, and 1 standard GFCI faceplate, screws and installed gasket Technical Information Model: 60HW Height: 4.192" Width: 5.836" Material: UV-Rated Plastic Style: Horizontal Trade Size: 1-Gang Color: White Documents Specification Sheet 60HW Line Drawing

Description Single Gang Device Box, Gangable, 2" Deep, 10 cu in with Raised Ground Screw, Cable Pryouts Ends, NMD90 and AC90 Gangable device boxes offer the option of constructing a box to hold two or more devices, Plaster ears allow box to be used in rework applications Technical Information Bracket Type: No Bracket Color: Gray Drawn or Welded: Welded Ends Cable: 4 Gangable: Yes Material: Steel Number of Gang(s) :1-Gang Plaster Ears: No Sub Brand tradeSELECT Type: Switch Box Wiring System: Non-Metallic Sheathed (NMD)/ Armoured Cable (AC) 14/2 8/3 Actual Depth 2 in Raised Ground Yes Weight 0.38 lb Cable Entry Universal Cable Clamps Certified Listed CSA Industry Standard(s) CSA Certified
