Load Centers

Description Leviton Load Centers deliver the fastest installing and most advanced circuit breaker panel on the market. They were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers that feature an entirely plug-on design for quick installation, saving time and labour cost. They are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your home’s electrical management hub. Leviton load centers are available in a wide variety of circuits, spaces, amp ratings, and can come with a main circuit breaker or main lugs, and with a regular white door or an observation window door. ****For security reasons, we cannot accept returns for load centers. Benefits Easy – All hot and neutral wires terminate at custom lugs in the panel, not at the circuit breaker, so the entire panel can be wired at rough-in without circuit breakers installed. Modern design – Galvanized steel, white powder coat enclosure housing provides a clean, neat appearance. Superior conductivity – All Leviton Load Centers come standard equipped with tin plated copper bussing. Organized – Notches stamped into the enclosure for cable ties promote secure and neat wiring. Safety – Meet and exceed CSA, UL 50, UL 50E, UL 67 and UL869A standards and certifications. Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Product Brochure Line Card

Description As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed, at final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Color indicators in the actuator handle designate operational status at-a-glance For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type of Load Center: Main Breaker Type: Indoor Without Window Ampage: 100 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 30 / 30 Voltage: 120/240 VAC Dimensions: 37" H x 14.25" W x 4" D / 39" H x 16.25" W Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 27.8 lbs / 18.6 lbs NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker Entire panel can be wired at rough-in without circuit breakers installed. At final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Amperage: 200 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 43" H x 14.25" W x 4" D / 45.3" H x 16.25" W Weight: 32.8 lbs / 20.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labor cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Mounting hardware included Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Amperage: 200 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 66/66 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 55.8" H x 14.3" W x 4" D Weight: 32.8 lbs / 22.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Outdoor Load Center is easy to install and weather resistant. It features a gray enclosure and a solid cover housing white circuit breakers. Hydraulic-Magnetic Trip Technology allows circuit breakers to operate as intended over a wide range of temperature extremes, -40°C to 70°C, without re-rating. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker* The entire panel can be wired at rough-in without circuit breakers installed At final installation, simply plug-on the circuit breaker No pigtails on circuit breakers Copper bus is standard Leviton GFCI, AFCI and Dual Function circuit breakers feature our patented reset lockout and will not reset if ground- or arc-fault protection is compromised Intuitive LEDs help communicate trip condition and type of fault (AF/GF) and remain illuminated even when the circuit breaker is in the tripped state *For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type of Load Center: Main Breaker Curent Rating: 100 A Spaces / Circuits: 20 / 20 Voltage: 120/240 V Busbar Material: Copper, Bright Tin-Plated Busbar Rating: 224A Enclosure Material: Galvanized Steel, Gray Baked Enamel Short Circuit Current Rating: 22 KA Dimensions: 30.31" H x 15" W x 4.56" D Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 42.75 lbs. NEMA Enclosure Type: NEMA3 Outdoor Operating Temperature: -40°C to 70°C Standards and Certifications CSA Std. C22.2 No. 29-15 Certificate 70170209 UL 67: File E480408 UL50 UL50E UL869A Documents Instruction Sheet Product Brochure Line Card

Description Leviton Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labour cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Mounting hardware included Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Breaker Ampage: 200 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 43" H x 14.25" W x 4" D / 45.3" H x 16.25" W Weight: 32.8 lbs / 22.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Outdoor Load Center is easy to install and weather resistant. It features a gray enclosure and a solid cover housing white circuit breakers. Hydraulic-Magnetic Trip Technology allows circuit breakers to operate as intended over a wide range of temperature extremes, -40°C to 70°C, without re-rating. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. Benefits Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker* The entire panel can be wired at rough-in without circuit breakers installed At final installation, simply plug-on the circuit breaker No pigtails on circuit breakers Copper bus is standard Leviton GFCI, AFCI and Dual Function circuit breakers feature our patented reset lockout and will not reset if ground- or arc-fault protection is compromised Intuitive LEDs help communicate trip condition and type of fault (AF/GF) and remain illuminated even when the circuit breaker is in the tripped state *For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type of Load Center: Main Breaker Current Rating: 200 A Spaces / Circuits: 20 / 20 Voltage: 120/240 V Busbar Material: Copper, Bright Tin-Plated Busbar Rating: 224A Enclosure Material: Galvanized Steel, Gray Baked Enamel Short Circuit Current Rating: 22 KA Dimensions: 30.31" H x 15" W x 4.56" D Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 42.75 lbs. NEMA Enclosure Type: NEMA3 Outdoor Operating Temperature: -40°C to 70°C Standards and Certifications CSA Std. C22.2 No. 29-15 Certificate 70170209 UL 67: File E480408 UL50 UL50E UL869A Documents Instruction Sheet Product Brochure Line Card

Description Take power to new heights with the award-winning Leviton Load Center – the industry’s most intelligent circuit breaker system available today. With optional smart circuit breakers, users can get insights on energy usage and control their panel like never before. As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits Revolutionary design allows the entire Load Center to be wired at rough-in without any circuit breakers present Come standard equipped with tin plated copper bussing Features a white, powder coated finish for a sleek, modern appearance Provides at-a-glance operational status of circuit breakers. Easily identify when a breaker has tripped, and the type of fault with intuitive LED diagnostics Entire panel can be wired at rough-in without circuit breakers installed, at final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Color indicators in the actuator handle designate operational status at-a-glance Technical Information Color: White Type: Indoor With Window Warranty: 10-Year Limited Amperage: 100 A Busbar Material: Copper, Bright Tin-Plated Dimensions: 43" H x 14.25" W x 4" D / 45.3" H x 16.25" W Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Supply Connections: 3 AWG - 300 MCM Cu/Al Type of Load Center: Main Breaker Voltage: 120/240 VAC Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Outdoor Meter Main Combo with 200A Main Circuit Breaker Factory Installed, 8 Spaces, NEMA 3R Rated. Includes Enclosure, Ring-Type Door, and Feed-Thru Lugs. Designed for use in Canada Features EASY – Leviton's revolutionary design allows the entire Load Center to be wired at rough-in without any circuit breakers present SUPERIOR CONDUCTIVITY – All Leviton Load Centers come standard equipped with tin plated copper bussing ORGANIZED – Notches stamped into the enclosure for cable ties promote secure and neat wiring. Technical Information Color: Gray Warranty: 10-Year Limited Amperage: 200 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 8 / 8 Type of Load Center: Meter Main Voltage: 120/240 VAC Busbar Material: Copper, Bright Tin-Plated Busbar Rating: 225A Dimensions: 37.11" H x 16.47" W x 5.2" D Enclosure Material: Galvanized Steel, Gray Baked Enamel Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 6 AWG – 350 MCM Weight: 56.8 lbs NEMA Enclosure Type: NEMA 3R Outdoor Operating Temperature: -40°C to 70°C In Compliance with CSA Std. C22.2 No.29, 94.2 and 0.19 as well as Standards UL 50, UL 50E, UL 67 and UL 869A Document Spec Sheet Instruction

Description As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers No pigtails on circuit breakers ever Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Ampage: 100 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 30 / 30 Voltage: 120/240 VAC Dimensions: 37" H x 14.25" W x 4" D / 39" H x 16.25" W Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 27.8 lbs / 16.6 lbs NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker Entire panel can be wired at rough-in without circuit breakers installed. At final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Lug Ampage: 225 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 43" H x 14.25" W x 4"/ 45.3" H x 16.25" W Weight: 30 lbs / 20.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker Entire panel can be wired at rough-in without circuit breakers installed. At final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Ampage: 225 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Voltage: 120/240 VAC Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 43" H x 14.25" W x 4" D / 45.3" H x 16.25" W Weight: 32.8 lbs / 20.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker Entire panel can be wired at rough-in without circuit breakers installed. At final installation, simply plug-on the circuit breaker Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Ampage: 150 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 43" H x 14.25" W x 4" D / 45.3" H x 16.25" W Weight: 32.8 lbs / 20.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labour cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Mounting hardware included Galvanized Steel, White Powder Coat NEMA 1 indoor, Flush/Surface Mount For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Lug Ampage: 200 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 30 / 30 Voltage: 120/240 VAC Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 37" H x 14.25" W x 4" D / 39" H x 16.25" W Weight: 25 lbs / 18.6 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton’s Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labour cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers No pigtails on circuit breakers Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Breaker Ampage: 125 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Weight: 22.8 lbs / 13.8 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton Indoor Load Centers are easy to install and feature a white enclosure for a modern, appealing unit. All hot and neutral wires terminate at custom lugs in the panel, not at the circuit breaker, so the entire panel can be wired at rough-in without circuit breakers installed. Leaving the option of having the circuit breakers easily plugged-on at final installation. ****For security reasons, we cannot accept returns on load centers. Benefits No pigtails on circuit breakers Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Lug Ampage: 125 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Weight: 20 lbs / 15.8 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton’s Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labour cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages, these new modern, aesthetically pleasing units are the smarter solution for your home's electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) No pigtails on circuit breakers Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring NEMA 1 with Main Breaker Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Breaker Amperage: 100 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Voltage: 120/240 VAC Busbar Material: Copper, Bright Tin-Plated Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 22.8 lbs / 15.8 lbs NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) No pigtails on circuit breakers Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Mounting hardware included NEMA 1 Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Lug Enclosure Material: Galvanized Steel, White Powder Coat Ampage: 225 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 42 / 42 Busbar Material: Copper, Bright Tin-Plated Dimensions: 43" H x 14.25" W x 4" / 45.3" H x 16.25" W Weight: 30 lbs / 22.3 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description Leviton Indoor Load centers were designed to provide you with an easy, quick and neat installation. They are the only branch circuit breakers in the market that feature an entirely plug-on design for quick installation, saving time and labour cost. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits All hot and neutral wires terminate at custom lugs in the panel, not at the circuit breaker, so the entire panel can be wired at rough-in without circuit breakers installed Galvanized steel, white powder coat enclosure housing provides a clean, neat appearance Optional observation window in the cover allows at-a-glance operating status of all the circuit breakers. Easily invertible for bottom feed applications Copper bus, standard feature on all Leviton Load Centers Notches stamped into the enclosure for cable ties promote secure and neat wiring. For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Ampage: 100 A Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Type of Load Center: Main Breaker Voltage: 120/240 VAC Busbar Material: Copper, Bright Tin-Plated Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Weight: 22.8 lbs / 13.8 lbs Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns for load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers Entire panel can be wired at rough-in without circuit breakers installed. (At final installation, simply plug-on the circuit breaker) Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring Terminate all hot and neutral wires at custom lugs in the panel, not at the circuit breaker For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor With Window Type of Load Center: Main Lug Ampage: 200 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 30 / 30 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 37" H x 14.25" W x 4" D / 39" H x 16.25" W Weight: 25 lbs / 16.6 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits An observation window in the cover allows at-a-glance operating status of all the circuit breakers No pigtails on circuit breakers ever Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire White indoor enclosure with optional observation window Technical Information Type: Indoor With Window Type of Load Center: Main Lug Ampage: 125 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Weight: 20 lbs / 13.8 lbs Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card

Description As the electrical hub of the home, safety starts at the load center. The Leviton Load Center is designed and engineered utilizing the latest safety technologies, incorporating GFCI, AFCI and Dual Function circuit breakers into the heart of the load center to help protect families and homes. These Load centers are free of excess wires and pigtails, allowing easy access during installation and for inspectors to check torque. With many advantages these new modern, aesthetically pleasing units are the smarter solution for your homes electrical management hub. ****For security reasons, we cannot accept returns on load centers. Benefits No pigtails on circuit breakers Easily invertible for bottom feed applications Copper bus is a standard feature on all load centers Notches stamped into the enclosure for cable ties promote secure and neat wiring For applications up to 60A when using copper wire; or 50A when using aluminum wire Technical Information Type: Indoor Without Window Type of Load Center: Main Breaker Ampage: 125 A Voltage: 120/240 VAC Short Circuit Current Rating: 22 KA Spaces / Circuits: 20 / 20 Dimensions: 30" H x 14.25" W x 4" D / 32" H x 16.25" W Busbar Material: Copper, Bright Tin-Plated Enclosure Material: Galvanized Steel, White Powder Coat Ground Connection: 4 AWG - 2/0 AWG Cu/Al Supply Connections: 3 AWG - 300 MCM Cu/Al Weight: 22.8 lbs / 13.8 lbs NEMA Enclosure Type: NEMA 1 Indoor Operating Temperature: 0°C to 40°C Standards and Certifications CSA: Yes UL 50: Yes UL 50E: Yes UL 67: Yes UL 869A: Yes Documents Instruction Sheet Product Brochure Line Card
