Description The Leviton Humidity Sensor and Fan Control automatically detects excess humidity in a room and activates the ventilation fan to lessen condensation, which helps reduce mold and mildew. Additionally, the device helps reduce energy usage by automatically operating the fan only when needed. The sensor uses a microprocessor combined with state-of-the-art digital sensing technology to continuously monitor and manage humidity levels when installed in areas of the home prone to condensation and mildew. It features user-friendly controls to adjust sensitivity, humidity level and time out settings. The sensor can replace a single pole switch (DHS05) or a combination switch (DHD05) and can be used with most bathroom or ventilation fans or fan/light combinations. These devices offer flexible installation options, including wiring with a neutral or by using an earth ground connection, and a slim profile for ease of installation. Features Ideal for Bathroom, basement, laundry room and home spa Replaces a single pole switch for control of a ventilation fan or fan/light combination Automatically detects excess humidity in a room and activates the ventilation fan to lessen condensation which helps reduce mold and mildew Helps reduce energy usage by automatically operating the fan only when needed For use with ventilation fans up to ¼ HP Compatible with LED, CFL, Incandescent, Halogen, MLV and ELV lighting loads Can be connected to Neutral wire if Neutral is present in the wallbox; or to Earth ground if no Neutral wire is present in the wallbox Interchangeable line and load wires saving installation time Microprocessor control with digital sensing technology Zero Cross turn-on technology extends the life of switching relays Advanced sensing enhances detection when the room is occupied and minimizes false triggers when unoccupied Operating Modes for bath fan, air cycle and humidistat Test mode to help with sensor placement and setting adjustments Can be used to comply with the requirements of 2019/2022 California Title 24, Part 6, Indoor Air Quality and Mechanical Ventilation Complies with the requirements of 2019/2022 CALGREEN, Part II, Indoor Air Quality and Exhaust Meets requirements of ASHRAE 6 Technical Information Adjustment: Programmable Color: White Dimensions: W 1.73" X D 0.95" X H 4.13" Grade: Residential LED Color: Green and Red Load Rating: 600W Incandescent, 300W LED/CFL, 400VA ELV, 400VA MLV, 1/4th HP Motor Neutral: Optional Power Consumption: <0.5 Watts Sensor Type: Humidity Style Name: Decora Switch: Relay Switch Type: Single-Pole Time Delay: 10, 20, 30 or 45 minutes Voltage: 120 VAC Wallplate: Not Included Warranty: 5-Year Limited Wiring: Ground or Neutral Required ASHRAE 62.2: Yes CALGREEN: Yes California Title 24: Yes Standards and Certifications: CSA Document Brochure Sensor Buying Guide Instruction

Description The Leviton Humidity Sensor and Fan Control automatically detects excess humidity in a room and activates the ventilation fan to lessen condensation, which helps reduce mold and mildew. Additionally, the device helps reduce energy usage by automatically operating the fan only when needed. The sensor uses a microprocessor combined with state-of-the-art digital sensing technology to continuously monitor and manage humidity levels when installed in areas of the home prone to condensation and mildew. It features user-friendly controls to adjust sensitivity, humidity level and time out settings. The sensor can replace a single pole switch (DHS05) or a combination switch (DHD05) and can be used with most bathroom or ventilation fans or fan/light combinations. These devices offer flexible installation options, including wiring with a neutral or by using an earth ground connection, and a slim profile for ease of installation. Features Ideal for Bathroom, basement, laundry room and home spa Replaces a combination switch for separate control of fan and lighting Automatically detects excess humidity in a room and activates the ventilation fan to lessen condensation which helps reduce mold and mildew Helps reduce energy usage by automatically operating the fan only when needed For use with ventilation fans up to ¼ HP Compatible with LED, CFL, Incandescent, Halogen, MLV and ELV lighting loads Can be connected to Neutral wire if Neutral is present in the wallbox; or to Earth ground if no Neutral wire is present in the wallbox Microprocessor control with digital sensing technology Zero Cross turn-on technology extends the life of switching relays Advanced sensing enhances detection when the room is occupied and minimizes false triggers when unoccupied Operating Modes for bath fan, air cycle and humidistat Test mode to help with sensor placement and setting adjustments Can be used to comply with the requirements of 2019/2022 California Title 24, Part 6, Indoor Air Quality and Mechanical Ventilation Complies with the requirements of 2019/2022 CALGREEN, Part II, Indoor Air Quality and Exhaust Meets requirements of ASHRAE 62.2 Color change kits are available in Black, Brown, Gray, Ivory, Light Almond and White (DHDKT-00x) Five-Year Limited warranty Technical Information Adjustment: Programmable Color: White Dimensions: W 1.73" X D 0.95" X H 4.13" Grade: Residential LED Color: Green and Red Load Rating: Fan Load (Blue Wire): 1/4 HP Fan, 300W LED/CFL, 600W Incandescent/Halogen, 400VA MLV/ELV. Light Load (Red Wire): 150W LED/CFL, 250W Incandescent/Halogen, 200VA MLV, 250VA ELV, 2A Resistive Mounting Type: Wall Switch Neutral: Optional Power Consumption: <0.5 Watts Sensor Type: Humidity Style Name: Decora Switch: Relay Switch Type: Single-Pole/Single Pole Time Delay: 10, 20, 30 or 45 minutes Voltage: 120 VAC Wallplate: Not Included Warranty: 5-Year Limited Wiring: Ground or Neutral Required ASHRAE 62.2: Yes CALGREEN: Yes California Title 24: Yes Standards and Certifications: CSA Document Brochure Sensor Buying Guide Instruction
